MSR 175PLUS Transportation Data Logger with GPS Tracking (for shock and climate)

Model:
MSR 175PLUS

Transport data logger with GPS/GNSS receiver · simultaneously records shocks with ±15 g and ±200 g as well as temperature, humidity, air pressure and light · stores 4 million total readings.

Add to wishlist
Description

Product features

  • High-speed shock logger with two simultaneously measuring internal acceleration sensors
  • Shock measurement mode: measurement always with ±200 g at 6400 Hz and with ±15 g at 1600 Hz simultaneously
  • 1 internal temperature, humidity, pressure and light sensor each; measurement frequency/storage rate every 10 min.
  • Setting of limit values
  • Installed memory is capable of storing over 4 million measured values
  • GPS/GNSS receiver
  • Rechargeable 2400 mAh lithium-polymer battery, recording time with activated GPS tracking approx. 8 weeks, without GPS tracking at least 1 year
  • Removable battery
  • Coloured LED for status indication
  • MSR175 software package with Dashboard software for easy start-up of the data logger, MSR ReportGenerator for automatic report generation and MSR ShockViewer for detailed analysis of shock events

The tamper-proof MSR175plus GPS data logger seamlessly captures potentially damaging shock events as well as recording the geographical position of the event. This robust data logger ensures compliance with transport specifications and provides indispensable data for identifying liability in the event of damage as well as helping with insurance claims.

Record important transport data for months at a time

The MSR175plus data logger's memory of over 4 million measurement values is sufficient to record data for days or months; over 1,000 shock or impact events can be recorded. The two acceleration sensors simultaneously record shocks in the measuring ranges of ±15 g and ±200 g. A measurement/storage rate of up to 6400 times per second is used. In addition, the robust mini data logger measures and stores temperature curves, humidity, air pressure and light. The 2400 mAh lithium-polymer battery, rechargeable via USB, ensures a long logger runtime - even with activated GPS tracking.

Locate critical transport events using GPS tracking

Where and when exactly did an event take place during transport or storage that was outside the preset tolerance limit? To enable you to answer this question quickly and conclusively, the MSR175plus is equipped with a GPS/GNSS (Global Navigation Satellite System) receiver. The satellite-supported position data is stored by the data logger, allowing the location of a transported item to be quickly determined and documented in the event of a damage.

Simple operation together with extensive evaluation options

The software package for the MSR175plus includes three programs: MSR175 Dashboard, MSR ReportGenerator and MSR ShockViewer. With the MSR Dashboard, configuring the MSR175 and reading measurement data via USB is child's play. To call up a clear report of the measurement data after transport, simply click on the MSR ReportGenerator. The basic version of the MSR ShockViewer is available for detailed evaluation of shock events.

Sensor Specifications

Internal sensorWorking rangeAccuracy (max. deviation)Measurement / Storage rate
3-axis-acceleration ±15 g and ±200 g (-20...+65 °C)

±15 g sensor

±0.15 g (0...5 g,+25 °C)

±0.3 g (5...15 g,+25 °C)



±200 g sensor

±2 g (0...15 g,+25 °C)

±5 g (15...100 g,+25 °C)

±10 g (100...200 g, +25 °C)

1600/s (±15 %)







6400/s (±15 %)

Temperature -20…+65 °C ±0.5 °C (-10…+65 °C) every 10 min.
Relative humidity 0...100 % rel. humidity
(-20…+65 °C)
±2 % rel. humidity
(10…85%, 0…+40 °C)
±4 % rel. humidity
(85…95%, 0…+40 °C)
every 10 min.
Air pressure, absolute 0…2000 mbar absolute
(-20…+65 °C)
±2.5 mbar
(750…1100 mbar
absolute, +25 °C
every 10 min.
Light 0…65,000 lx max. sensitivity at 500 nm every 10 min.



General technical data of the MSR175plus Data Logger

Memory capacity:

Over 4,000,000 measurement values.

GNSS position data: GPS (optional: GLONASS, Galileo, Beidou)
Medium: Air
Key: Start measurement/retrieve status/test GPS reception.
Power supply: Lithium-polymer battery 2400 mAh, rechargeable via USB connection, recording time with activated GPS tracking approx. 8 weeks, without GPS tracking at least 1 year.
Interface: USB
Software package: MSR175 Dashboard software, MSR ReportGenerator, free MSR ShockViewer basic version. A fee-based MSR ShockViewer Pro Version will be available at a later stage. System requirements: Windows 7 or higher, USB port.
Operating conditions:
Temperature: -20…+65 °C
Storage conditions:
Temperature:
Humidity:
+5…+45 °C (ideal storage condition for the battery)
10…95 % relative humidity, non-condensing
Standards: The MSR175plus complies with EU-Directives RoHS/WEEE.
